CC-TSV211 51306665-175 | HONEYWELL Servo Valve Positioner Module

in stock#

Brand/ Manufacturer:
HONEYWELL
Dimensions:
12x14.5x5.2cm
Weight:
0.18 kg
Country of Origin: :
USA
Description:
HONEYWELL CC-TSV211 51306665-175 Servo Valve Positioner Module

Inquiry now

Mfr. Part Number:	CC-TSV211 51306665-175

Manufacturer:	HONEYWELL

Description:	HONEYWELL CC-TSV211 51306665-175 Servo Valve Positioner Module

Full Description:	The CC-TSV211 51306665-175 Servo Valve Positioner Module featuring galvanic isolation up to ±500 VDC

Status:	In stock

Click to get price : : plcinfo@mooreplc.com : +86 18020776786 : mooreplc

Moore Automation Limited is not affiliated with or a distributor for HONEYWELL. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

Product Description:
The CC-TSV211 51306665-175 Servo Valve Positioner Module provides an onboard PID positioning loop for positioning a servo valve typically used in a turbomachinery control application. It can accept LVDT/RVDT/4-20 mA position feedback signals from the control valve, receive a control valve demand remote set point from a C300-20msCEE controller and execute onboard PID positioning loop to issue current output to servo valve coil to control the control valve position.

The CC-TSV211 51306665-175 module is featuring galvanic isolation up to ±500 VDC to ensure safe operation and strong immunity against electrical interference in industrial environments. The A/D converter provides 16-bit resolution, enabling high-precision signal acquisition for accurate valve positioning control.With an input scan rate of 2.5 ms, the CC-TSV211 51306665-175 ensures fast response and real-time processing capability.

Application:

Oil and gas: Offshore drilling platforms for refineries, emergency stop and status monitoring systems for oil production plants.
Electricity industry: Auxiliary machine control in power plants, signal integration for DCS (Distributed Control System).
Pharmaceutical industry: Automated production lines in pharmaceutical factories, environmental monitoring systems for clean rooms.
Pulp and paper industry: Logic control and process automation for large paper machines.

Frequently Asked Questions (FAQ)

Q:What is the input scan rate of CC-TSV211 51306665-175?
A:The CC-TSV211 51306665-175 has an input scan rate of 2.5 ms for fast real-time control.

Q:How many output channels does CC-TSV211 51306665-175 have?
A:The CC-TSV211 51306665-175 has 2 output channels for driving servo valve coils.

Q:Is CC-TSV211 51306665-175 brand new?
A:Yes, CC-TSV211 51306665-175 is brand new, original, unused, and factory sealed.

If you need other brands products like below, please feel free write email to plcinfo@mooreplc.com

You will get Best price and Professional service (24/7)

Detailed Parameter	Part Number: CC-TSV211 51306665-175
Resolution	16-bit DAC
Maximum Open Circuit Voltage	±14 V
Gap (0 mA) of Output to Field on Switchover	15 ms maximum
Galvanic Isolation	±500 VDC
A/D Converter Resolution	16-bit
Input/Output Range	8 V RMS max., 2.5–3.2 kHz
Input Impedance	> 25 kΩ
Input Scan Rate	2.5 ms
