Bently Nevada 990-05-XX-01-00 MOD:289549-17 2-wire loop-powered vibration transmitter

Description

The Bently Nevada 990-05-XX-01-00 MOD:289549-17 Vibration Transmitter provides a direct interface between a machine vibration measurement point and an industrial monitoring or control system. The transmitter receives the vibration signal from a compatible seismic or velocity sensor and converts the measured vibration into a proportional 4-20 mA output signal for process monitoring, control, and machinery protection applications. The 990 Vibration Transmitter is designed for applications where a simple and reliable vibration monitoring solution is required without the need for a separate rack-based monitoring system. It provides continuous vibration measurement by conditioning the sensor input signal and transmitting the corresponding output signal to PLCs, DCS systems, or other plant control equipment. The 990-05-XX-01-00 configuration includes a standard transmitter arrangement with integral signal conditioning functions. The unit provides a convenient solution for monitoring general industrial rotating machinery where overall vibration level measurement is required. The transmitter can be installed close to the monitored equipment and connected directly to plant instrumentation systems.

Parameter

Model: 990-05-XX-01-00 MOD:289549-17 2-wire loop-powered vibration transmitter
Full-scale Option: 0-5 mils pp (0-125 μm pp)
Mounting Option: 35 mm DIN rail clips
Agency Approval Option: Not required
Frequency Response: 5 Hz to 6,000 Hz (+0, -3 dB)
Full-scale: 0-5 mils pp (0-125 μm pp)

Frequently asked questions

Q:What is the main function of the Bently Nevada 990-05-XX-01-00 MOD:289549-17?
A:Converts vibration signals from a compatible proximity measurement system into a proportional 4-20 mA output signal for connection with industrial monitoring and control systems.

Q:What does MOD:289549-17 indicate?
A:MOD:289549-17 identifies a specific factory modification configuration of the 990 Vibration Transmitter. The modification defines the transmitter setup according to the required measurement range, system configuration, and application requirements.

Q:What should be confirmed before replacing a 990-05-XX-01-00 MOD:289549-17?
A:The vibration measurement range, sensor type, mounting configuration, output requirements, and existing control system interface should be confirmed before replacement to ensure correct operation.

Application areas

• Industrial Rotating Machinery–Applied on various rotating machines where a simple vibration measurement signal is required without the need for a rack-based monitoring system. The transmitter provides a direct interface between vibration measurement points and plant instrumentation systems.
• OEM Machinery Packages–Suitable for OEM equipment packages that require an integrated vibration monitoring output connected to existing machinery control systems.
• Process Industry Equipment–Used in industrial facilities where rotating equipment operates continuously and vibration information is required for equipment monitoring and maintenance planning.
