Bently Nevada 200151-20-03-00 accelerometer interface cable

Parameter
Model: 200151-20-03-00 accelerometer interface cable
Cable Length: 20-2.0 meters
Armor Option: 03-Blue cable with armor
Coupling Nut: 00-Standard coupling nut (see Figure 9)
Minimum Bend Radius: 63.5 mm (2.5 in)
Max Cable Length: 25 m (82 ft)

Description

The Bently Nevada 200151-20-03-00 is an Accelerometer Interface Standard Cable designed for use with Bently Nevada 200150, 200155, and 200157 Accelerometers. This configuration features a 2.0 m cable length, a blue cable with armor, and a standard coupling nut. The armored cable construction provides additional mechanical protection for installations where cable protection is required. The standard coupling nut allows connection with compatible accelerometer assemblies specified for the system. The 200151 series interface cable is used to maintain the electrical connection required between the accelerometer and monitoring equipment. When installed with compatible Bently Nevada accelerometers, it supports vibration measurement applications by transferring sensor output signals to the associated monitoring system.

Frequently asked questions

Q:Where is the 200151-20-03-00 commonly installed?
A:The cable is commonly used with rotating machinery monitoring systems installed on motors, pumps, compressors, fans, and other industrial equipment requiring vibration measurement.

Q:What type of cable construction is included?
A:This model uses a blue cable with armor, providing additional mechanical protection for industrial installation environments.

Q:What should be checked before replacing the 200151-20-03-00?

A:The cable length, cable construction, coupling nut type, connected accelerometer model, and monitoring system compatibility should be verified before replacement.

Application areas

• Power Generation Equipment–Applied on rotating machinery in power plants where casing vibration monitoring is required for equipment protection and maintenance planning.
• Oil and Gas Facilities–Used with accelerometer-based monitoring systems installed on motors, pumps, compressors, and other rotating machinery in production and processing facilities.
• Petrochemical Plants–Supports vibration monitoring applications on continuous-operation process equipment requiring reliable sensor signal transmission.
• General Industrial Machinery Monitoring–Used in Bently Nevada accelerometer installations for casing vibration measurement, machinery condition monitoring, and vibration data collection.
