Vibro-Meter TQ403 111-403-000-012 Non-contact Eddy-current Proximity Transducer

Parameter
Model: TQ403 111-403-000-012 Non-contact Eddy-current Proximity Transducer
Frequency response: DC to 20 kHz (−3 dB)
Measurement range: 12 mm
Temperature range: −40 to +180 °C
Linear Measurement Range: 0.75 to 12.75 mm
Output (Voltage): -1.6 V (min gap) to -17.6 V (max gap)
Output (Current): -15.5 mA (min gap) to -20.5 mA (max gap)

Description

The Vibro-Meter TQ403 111-403-000-012 is a non-contact eddy-current proximity transducer designed for accurate measurement of shaft relative vibration, axial position, and gap in rotating machinery. As part of the TQ403/EA403/IQS450 proximity measurement system, it works with the EA403 extension cable and IQS450 signal conditioner to provide a calibrated, interchangeable measurement chain with either voltage or current output. The system features a 12 mm measuring range, DC to 20 kHz frequency response, and a temperature-compensated design for stable performance. Operating over a −40 to +180 °C temperature range, with IP68 protection at the transducer tip and integral cable, the TQ403 is available in Ex-certified versions for hazardous areas and is particularly suited for use with VM600Mk2, VM600, and VibroSmart® machinery monitoring systems.

Frequently asked questions

Q:What is the Vibro-Meter TQ403 111-403-000-012?
A:The TQ403 111-403-000-012 is a non-contact eddy-current proximity transducer designed to measure shaft relative vibration, axial position, and gap in rotating machinery as part of the TQ403/EA403/IQS450 proximity measurement system.

Q:What measurement range does the TQ403 111-403-000-012 provide?
A:It offers a 12 mm measurement range, making it suitable for both static displacement and dynamic vibration monitoring.

Q:Can the TQ403 be replaced without recalibrating the entire system?

A:Yes. The TQ403, EA403 extension cable, and IQS450 signal conditioner are fully interchangeable within the calibrated system, simplifying maintenance and replacement.

Application areas

The Vibro-Meter TQ403 111-403-000-012 is a non-contact eddy-current proximity transducer featuring a large 12 mm measuring range. It is primarily used in industrial condition monitoring chains for axial position (large-scale thrust displacement), shaft relative vibration, and static gap measurements.

• Power Generation & Energy: Widely used in large-scale thermal, gas turbine, nuclear, and hydro power plants to provide critical asset protection for heavy turbomachinery.
• Petroleum & Natural Gas: Deployed in offshore platforms, refineries, and gas pipeline compressor stations to monitor critical driven equipment.
• Heavy Chemical & Metallurgy: Applied to high-pressure compressor trains in ethylene cracking plants and fertilizer plants, as well as large blast furnace blowers in steel mills.
