WOODWARD 8280-192 low-voltage digital speed controller

Frequently asked questions
Q:What is the WOODWARD 8280-192?
A:The 8280-192 is a 701A Digital Speed Control used to regulate the speed of reciprocating engines in mechanical drive and generator set applications. It operates with a magnetic pickup (MPU) speed input and a low-voltage DC power supply.

Q:Can the 8280-192 accept a remote speed reference?
A:Yes. A 4–20 mA analog input is available for remote speed adjustment, allowing the engine speed reference to be controlled from an external device.

Q:What types of engines can use the 8280-192?
A:The controller is suitable for reciprocating engines used in generator sets and mechanical drive systems, including diesel, gas, and dual-fuel engines equipped with compatible governor actuators.

Description

The Woodward 8280-192 is a 701A digital speed control designed for reciprocating engines equipped with a magnetic pickup (MPU) speed sensor. The control operates from an 18–40 Vdc power supply and delivers a 0–200 mA actuator output for electronic governor applications. It measures engine speed from the magnetic pickup input and adjusts actuator current to maintain the programmed operating speed under changing load conditions. The controller includes configurable operating parameters for speed setting, droop, torque limiting, start fuel, idle speed, and dynamic response. Remote speed adjustment is available through a 4–20 mA input, while a 4–20 mA tachometer output can be used for external monitoring equipment. Programming and parameter adjustment are completed with the compatible Woodward hand-held programmer without requiring hardware modifications.

Parameter

Model: 8280-192 low-voltage digital speed controller
Power Supply: 18-40 Vdc (nominal 24/32 Vdc)
Power Consumption: 8 W (typical)
Actuator Output: 0–200 mA (proportional)
Remote Speed Input: 4-20 mA / 1-5 Vdc
Speed Regulation: ±0.25% (isochronous)
Ambient Operating Temp: -40°C to +70°C (-40°F to +158°F)
Storage Temp: -55°C to +105°C (-67°F to +221°F)
Relative Humidity Limit: 5% to 95% RH (Non-condensing)

Application areas

• Isolated Island and Microgrid Power Plants: Regulates diesel engines providing primary power to remote mining communities or off-grid construction sites, utilizing its adjustable "Droop" parameter to allow proportional load-sharing between multiple paralleled generators.
• Shipboard Auxiliary Generator Units: Manages the diesel engines that power a vessel's internal electrical grid, ensuring that starting large electric winch motors or bow thrusters does not cause transient frequency drops.
• Emergency Marine Fire Pumps: Governs standalone emergency diesel engines driving high-capacity fire water pumps, operating reliably via its rugged -40 °C to 70 °C environmental chassis.
