Bently Nevada 330185-02 3300 XL Precision Micrometer

Brand/ Manufacturer:
Bently Nevada
Dimensions:
8.8 x 3.5 x 7cm
Weight:
0.2kg
Country of Origin: :
USA
Description:
Bently Nevada 330185-02 3300 XL Precision Micrometer

Inquiry now

Part Number:	330185-02

Manufacturer:	Bently Nevada

Description:	Bently Nevada 330185-02 3300 XL Precision Micrometer

Full Description:	The Bently Nevada 330185-02 is a metric (0-25 mm) calibration micrometer designed to verify the scale factor and linearity of 3300 XL proximity transducer systems


Status:	In stock ready to ship

Moore Automation Limited is not affiliated with or a distributor for Bently Nevada. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

Sales manager: Tiffany Guan plcsale@mooreplc.com + 86 18030235313 2851195473

Description

The Bently Nevada 330185-02 is a 3300 XL Precision Micrometer designed for verifying the performance of 3300 XL proximity transducer systems. Featuring a 0–25 mm measuring range 0.0005 mm resolution and ±0.0004 mm accuracy, it provides precise, repeatable probe positioning during calibration and system verification.The micrometer moves the target toward or away from the proximity probe in calibrated increments allowing the output from the Proximitor Sensor to be measured and compared with expected values.

Parameter

Model: 330185-02 3300 XL Precision Micrometer
Scale Units: 02-Micrometer in metric units (0- 25 mm)
Measuring Range: 0-25 mm
Maximum Permissible Error (Accuracy): ±0.0004 mm
Design Standards: Meets API 670 standard requirements for proximity transducer system acceptance testing

Frequently asked questions

Q:What is the Bently Nevada 330185-02?
A:The 330185-02 is a 3300 XL Precision Micrometer with metric scale units (0–25 mm). It is designed for verifying the performance of Bently Nevada 3300 XL proximity transducer systems.

Q:What is the primary purpose of the 330185-02?
A:It is used to verify and calibrate Bently Nevada 3300 XL proximity transducer systems by moving a target at precise increments to test sensor voltage output.

Q:What measuring range does the 330185-02 provide?
A:The metric version provides a measuring range of 0 to 25 mm.

Application areas

The Bently Nevada 330185-02 metric precision micrometer is primarily used for proximity transducer calibration and performance verification in heavy industrial asset condition monitoring.

Large Pumps and Fans: Calibrating displacement sensors in high-speed power plant or water treatment pumps.
Steam and Gas Turbines: Ensuring precise shaft vibration (radial dynamic motion) and thrust (axial position) monitoring.
Oil & Gas (Refineries / Petrochemical): Upstream drilling facilities and downstream refinery plants with massive rotating machinery.
Heavy Manufacturing & Mining: Steel mills and mining sites running high-power turbomachinery.
