330500-08-01 | Bently Nevada Velomitor Piezo-velocity Sensor

in stock#

Brand/ Manufacturer:
Bently Nevada
Dimensions:
6.7x2.4x2.4cm
Weight:
0.14kg
Country of Origin: :
USA
Description:
Bently Nevada 330500-08-01 Velomitor Piezo-velocity Sensor

Inquiry now

Mfr. Part Number:	330500-08-01

Manufacturer:	Bently Nevada

Description:	Bently Nevada 330500-08-01 Velomitor Piezo-velocity Sensor

Full Description:	The 330500 is a specialized piezoelectric accelerometer that incorporates embedded integrated electronics in a solid-state design.

Status:	In stock

Click to get price : : plcinfo@mooreplc.com : +86 18020776786 : mooreplc

Moore Automation Limited is not affiliated with or a distributor for Bently Nevada. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

Product Description:

The Bently Nevada 330500-08-01 Velomitor Piezo-Velocity Sensor is a dedicated Velomitor piezo-velocity sensor designed for absolute housing vibration monitoring of heavy-duty industrial rotating machinery. It provides critical predictive maintenance data to prevent catastrophic equipment failures. The Bently Nevada Velomitor piezo-velocity sensor measures absolute (relative to free space) vibrations of bearing housings, housings, or structures. The 330500 is a dedicated piezo-accelerometer with a solid-state design and integrated electronics.

Application:

Pumps: Monitors cavitation, bearing degradation, and misalignment in high-pressure water, chemical, or oil pumps.
Centrifugal & Axial Compressors: Tracks high-speed rotor stability and housing imbalances in gas processing plants.
Electric Motors: Evaluates mechanical imbalances, loose rotor bars, and bearing wear on large industrial drive motors.
Industrial Fans & Blowers: Measures casing vibration caused by blade fouling, structural resonance, or aerodynamic instability.

Frequently Asked Questions (FAQ)

Q:What is the difference between this and traditional moving-coil sensors?

A:The 330500 is a solid-state piezoelectric accelerometer featuring embedded integration electronics. It has no moving parts, meaning it is immune to mechanical wear, cross-axis vibration degradation, and strict orientation mounting limits.
Q:How should it be powered safely?
A:The sensor requires an external power source of 22 to 30 VDC. It is critical to use a constant current diode (limiting current to 2.5 to 6 mA) to prevent sensor damage. Compatible Bently Nevada monitoring modules supply this automatically.

Q:What are the recommended cabling boundaries?
A:It uses a 2-pin MIL-C-5015 hermetic connector. You can run twisted, shielded terminal cabling up to a maximum length of 305 meters (1,000 feet) without experiencing signal degradation.

If you need other brands products like below, please feel free write email to plcinfo@mooreplc.com

You will get Best price and Professional service (24/7)

Detailed Parameter	Part Number：330500-08-01
Sensitivity	3.94 mV/mm/s (100 mV/in/s) ±5%
Temperature Sensitivity	-14% to +7.5% typical over the operating temperature range
Velocity Range	1270 mm/s (50 in/s) peak
Transverse Sensitivity	Less than 5% of sensitivity
Amplitude Linearity	±2% to 152 mm/s (6 in/s) peak
Dynamic Output Impedance	Less than 2400 Ω
Grounding	Case isolated
Operating Temperature Range	-55°C to 121°C (-67°F to 250°F)
Shock Survivability	5,000 g peak, maximum
Mounting Thread Adaptor Option	1/2 – 13 UNC
Agency Approval Option	CSA/US/C
