2711R-T10T | | 2711RT10T

Brand/ Manufacturer:
Dimensions:
38.5cm*31cm*16cm
Weight:
2.42kg
Country of Origin: :
United States
Description:
PANELVIEW 800 10.4-INCH HMI TERMINAL

Inquiry now

Mfr. Part Number:	2711R-T10T

Manufacturer:

Description:	The 2711R-T10T is a PanelView 800 graphic terminal. This Human Machine Interface (HMI) device is powered by an external supply voltage of 24VDC. It has a 10.0-inch Color transmissive TFT active-matrix LCD

Full Description:	It has a variety of communication ports such as, One (1) RS232/RS422/485 and One (1) Ethernet, USB port and micro-SD card slot.

Sales manager: Tiffany Guan plcsale@mooreplc.com + 86 18030235313 dddemi33 2851195473

The 2711R-T10T is a PanelView 800 Graphic operator terminal. This operator terminal is equipped with modern specifications that fits today’s industrial application requirements. This operator terminal supports landscape and portrait orientation, providing mounting flexibility and optimized process flow design.

The 2711R-T10T features a Central Processing Unit (CPU) with processing speed of 800 MHz. It also has a significantly improved memory area having a dedicated 256 MB internal storage and 256 MB DDR RAM.

The 2711R-T10T has a 10-inch TFT touch screen, wide LCD display screen with resolution of 800 x 600 SVGA and supports 65K colors. It has a LED backlight with operational lifespan of 40,000 hours. This operator terminal is provided with a micro-SD card.

Recommended SD cards are industrial grade SD cards, SDSC and Class 6 & Class 10 0 SDHC micro-SD cards. Supported card formats are FAT32 / FAT16 formats and supports up to 32 GB storage size. Additionally, the provided USB ports supports installation of external flash drive for removable storage.

The 2711R-T10T comes with One (1) RS-422 and RS-485 port, One (1) RS-232 port and One (1) Ethernet communication ports. Serial interfaces support system protocols such as DF1, DH485, MODBUS, MODBUS ASCII, MODBUS unsolicited and Common Industrial Protocol (CIP) while the provided Ethernet port supports CompactLogix, MicroLogix, MicroLogix ENI, SLC 500, MODBUS TCP/IP and CIP as well.
