1794-OM8 | PLC Digital Output Module

in stock#

Brand/ Manufacturer:
PLC
Dimensions:
20.3x5.1x10.2cm
Weight:
0.29 kg
Country of Origin: :
USA
Description:
PLC 1794-OM8 Digital Output Module

Inquiry now

Mfr. Part Number:	1794-OM8

Manufacturer:	PLC

Description:	PLC 1794-OM8 Digital Output Module

Full Description:	The 1794-OM8 is a PLC digital output module with 8 outputs

Status:	In stock

Click to get price : : plcinfo@mooreplc.com : +86 18020776786 : mooreplc

Moore Automation Limited is not affiliated with or a distributor for PLC. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

Product Description:

The PLC 1794-OM8 is a 1794 FLEX Digital Output Module. It is fitted inside the terminal bus, making a connection with the field devices and the I/O bus. Modules can be inserted or removed under power since the I/O module does not have any direct wiring. It in turn saves time and removes system restarting inefficiency.

The 1794-OM8 module has 8 outputs. It has 220V AC nominal On-State output voltage 159 – 264V AC On-State output voltage range 500mA maximum and 5mA minimum at 55 °C current per output and 4A (8 outputs at 500 mA) maximum current per module. It has a maximum power dissipation of 5W at 0.5A. It has various communication options such as ControlNet, DeviceNet, EtherNet/IP, and Universal Remote I/O. The 1794-OM8 module has 16 yellow LED status indicators for each channel indicating the corresponding input device and output signal.

Application:

Electricity and Energy: Control the AC contactors, heaters or electric actuators within the distribution cabinet.
Water Treatment: Drive small AC pumps, electric valves, and the agitator motor of the dosing system.
Infrastructure and Transportation: Tunnel lighting control, AC fans for the building ventilation system (HVAC) start and stop.
Food and Chemicals: Control the AC contactors of the conveyor belt drive motor, heating tubes of industrial furnaces.

Frequently Asked Questions (FAQ)

Q:What is the main function of the 1794-OM8 module?
A:The 1794-OM8 is a PLC digital output module with 8 outputs, used to control actuators in industrial automation systems.

Q:What is the on-state current of the 1794-OM8?
A:The 1794-OM8 has a minimum on-state current of 50 mA per output.

Q:How are the 1794-OM8 packaged?
A:1794-OM8 packaging generally involves multiple layers of protection to ensure safe transit.

If you need other brands products like below, please feel free write email to plcinfo@mooreplc.com

You will get Best price and Professional service (24/7)

Detailed Parameter	Part Number: 1794-OM8
Number of Outputs	8
Output Current Rating	4.0 A (8 outputs @ 500 mA)
On-state Current	50 mA per output minimum
Surge Current	7 A for 40 ms
Flexbus Current	60 mA @ 5 V DC
Power Dissipation	5.0 W maximum @ 0.5 A
Thermal Dissipation	17.1 BTU/hr maximum @ 0.5 A
Storage Temperature	-40 to 85 °C (-40 to 185 °F)
Relative Humidity	5 to 95% non-condensing
Shock (Operating)	30 g
