2097-V33PR1 | | servo drive

Technical Specifications for 2097-V33PR1
Part Number/Catalog No.: 2097-V33PR1
Input Voltage: 80-132VAC, 1-Phase 80-264VAC, 1-Phase 80-264VAC, 3-Phase
Integrated AC Line Filter: No
Brand:
Manufacturer: Automation
Product Bulletin: 2097 Kinetix 300 Drives
Product Description: 2097 Kinetix 300 Ethernet I/P Indexing Drives
Input Frequency: 48…62 Hz
Main AC input current, Nom (rms) 120/240V input, single-phase: 5.0 A
Max inrush (0-pk) 120/240V input: 68.0 A
Nom (rms) 240V input, three-phase: 3.0 A
Max inrush (0-pk) 240V input: 136 A
Control power back-up input voltage: 20…26V DC
Control power back-up input current, nominal: 500 mA
Control power back-up input current, max. inrush: 30 A

About 2097-V33PR1
The 2097-V33PR1 is a Kinetix 300 Ethernet I/P Indexing Servo Drive. This drive is capable of being operated with a variety of voltage inputs such as 80-132VAC rms, 1-phase with 120VAC nominal input, 80-264VAC rms, 1-phase with 240VAC nominal and 80-264V rms, 3-phase with 240VAC nominal input voltages. This drive has a continuous output power of 0.5 kW and Continuous output current of 2.8 Amperes.

The 2097-V33PR1 is integrated with a safe Torque-Off feature. Safe Torque is used to disabled the drive output and remove torque without removing power to the system. The safe torque-off feature is certified at ISO 13849-1 PLd/SIL2.For compliance with EN954-1, installation of an external safety is required relay to meet Category 3. Aside from the safe Torque-off, also has built-in overvoltage and short-circuit protection with ratings of 430V DC and 100,000 A (rms) symmetrical, respectively.

The 2097-V33PR1 has a single Ethernet I/P port which can be used for implementing motion control over Ethernet I/P, communication with control systems such as Remote I/O devices and Human Machine Interfaces.

When configuring the motor to communication and control, use RSLogix 5000 or Studio 5000 Design environment programming software. These programming software packages may be imported with Add-on profiles, specifically used for the Kinetix 350 indexing servo drives. This controller may integrate with the Logix controller platform seamlessly, especially with CompactLogix controllers as part of ’s Integrated Architecture System. Aside from controllers, this drive may control and integrate with MP series and TL series servo motors and actuators.
