200350-09-00-CN | Bently Nevada Accelerometer

in stock#

Brand/ Manufacturer:
Bently Nevada
Dimensions:
8.3x3.5x3.2cm
Weight:
0.3kg
Country of Origin: :
USA
Description:
Bently Nevada 200350-09-00-CN Accelerometer

Inquiry now

Mfr. Part Number:	200350-09-00-CN

Manufacturer:	Bently Nevada

Description:	Bently Nevada 200350-09-00-CN Accelerometer

Full Description:	The 200350 Accelerometers are general purpose, case-mounted seismic transducers designed Card

Status:	In stock

Click to get price : : plcinfo@mooreplc.com : +86 18020776786 : mooreplc

Moore Automation Limited is not affiliated with or a distributor for Bently Nevada. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

Product Description:

The Bently Nevada 200350-09-00-CN is a rugged, case-mounted seismic accelerometer engineered. It targets industrial sectors requiring continuous condition monitoring to prevent catastrophic mechanical failures in harsh environments.The 200350-09-00-CN Accelerometers is contained within a hermetically sealed, stainless steel case. The design provides an extremely rugged transducer, well suited for harsh industrial environments. Each transducer’s top mounted, 2-pin connector (MIL-C5015) allows for easy installation and removal of the interconnecting signal cable. A ¼-28 threaded hole on the bottom of the casing accommodates multiple mounting options.

Application:

Cooling Tower Fans: Detecting structural looseness and gear teeth pitting in wet environments.
Boiler Feed Pumps: Monitoring cavitation-induced casing shocks.
Small-to-Medium Compressors: Catching high-frequency valve impacts or casing vibrations.
Submersible Pumps: Managing casing acceleration despite fluid turbulence.

Frequently Asked Questions (FAQ)

Q:What are its environmental temperature limitations?
A:The sensor can reliably operate in severe industrial climates with temperatures ranging from -54°C to +121°C (-65°F to +250°F).
Q:How does it connect to a data cable?
A:The top of the accelerometer housing features an integrated 2-pin MIL-C-5015 twist-lock connector. This standard industrial connection allows field technicians to easily disconnect and swap cables without unmounting the sensor body.

Q:Can this sensor withstand harsh industrial environments?
A:Yes. The 200350 accelerometer features a hermetically sealed, stainless steel case, offering extreme ruggedness against moisture, dust, and corrosive industrial atmospheres. It holds an IP68 waterproof rating and can handle 100% relative condensing humidity.

If you need other brands products like below, please feel free write email to plcinfo@mooreplc.com

You will get Best price and Professional service (24/7)

Detailed Parameter	Part Number：200350-09-00-CN
Mounting Stud	No mounting stud
Tolerance	100 mV/g ± 20% (10.2 mV/m/s^2 ±20%)
Sensitivity	100 mV/g ±20% (10.2 mV/m/s^2 ±20%)
Measurement Range	± 50 g
Transverse Sensitivity	≤ 7%
Amplitude Linearity	± 1%
Output Bias Voltage	8 to 12 VDC
Excitation Voltage	18 to 28 VDC
Constant Current Excitation	2 to 20 mA
Operating Temperature Range	-65°F to +250 ºF (-54°C to +121 ºC)
Shock Survivability	5,000 g pk
