190501-15-00-04 | Bently Nevada Velomitor CT Velocity Transducer

in stock#

Brand/ Manufacturer:
Bently Nevada
Dimensions:
3.6x3.1x10cm
Weight:
0.38kg
Country of Origin: :
USA
Description:
Bently Nevada 190501-15-00-04 Velomitor CT Velocity Transducer

Inquiry now

Mfr. Part Number:	190501-15-00-04

Manufacturer:	Bently Nevada

Description:	Bently Nevada 190501-15-00-04 Velomitor CT Velocity Transducer

Full Description:	The Velomitor CT Velocity Transducer is a low-frequency version of our standard Velomitor Piezo-velocity Sensor.

Status:	In stock

Click to get price : : plcinfo@mooreplc.com : +86 18020776786 : mooreplc

Moore Automation Limited is not affiliated with or a distributor for Bently Nevada. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

Product Description:

The Bently Nevada 190501-15-00-04 is a specific configuration of the Velomitor CT (Cooling Tower) Velocity Transducer, a low-frequency version of the standard Velomitor Piezo-velocity Sensor. Its design specifically measures casing vibration velocity on cooling tower and air-cooled heat-exchanger fan assemblies that operate at or above 90 rpm (100 to 300 rpm typical). The Velomitor CT Transducer can measure vibration amplitudes at these frequencies as well as the vibration frequencies generated by the fan motor and speed reducers.

Application:

Cooling Tower Fan Assemblies: Measures casing vibration velocity on large cooling fans used in industrial facilities, thermal power plants, and HVAC systems.
Air-Cooled Heat Exchangers (Fin-Fans): Monitors mechanical health across large radiator-style cooling bays in refineries and petrochemical complexes.
Industrial Gearboxes / Speed Reducers: Tracks vibration frequencies generated by the gear reduction system linked to slow-moving rotors.
Fan Drive Motors: Assesses the reliability and balance of the primary drive motors powering heavy ventilation equipment.

Frequently Asked Questions (FAQ)

Q:How can you test or calibrate the low-frequency response?
A:Field loop checks cannot be accurately completed using traditional high-frequency shakers. Testing must be performed using a specialized low-frequency portable vibration calibrator capable of driving verification profiles as low as 42 cpm to ensure alerts and alarms are functional.
Q:How do you mount and torque this sensor?
A:The mounting surface requires a 33 mm (1.3 in) diameter flat area. You must apply a mounting torque of 4.5 N-m ± 0.6 N-m (40 in–lbf ± 5 in-lbf). Incorrect torque will compromise frequency response or cause false readings.

Q:Which monitoring systems are compatible with this transducer?
A:It is fully compatible with Bently Nevada 3500 Machinery Protection Systems via the 3500/42M Proximitor Seismic Monitor module. For newer Orbit 60 systems, Bently Nevada recommends using the PAV (Position/Acceleration/Velocity) module rather than the PVT module to safely match the sensor's power limit constraints.

If you need other brands products like below, please feel free write email to plcinfo@mooreplc.com

You will get Best price and Professional service (24/7)

Detailed Parameter	Part Number：190501-15-00-04
Mounting Hardware Option	Adapter, 3/8-in 24 to 5/16-in 18
Connection Option	MIL-C-5015 connection interface
Sensitivity	3.94 mV/mm/s (100 mV/in/s) ±5%
Temperature Sensitivity	-8% to +5% typical over the operating temperature range
Transverse Response	Less than 5% of the axial sensitivity
Output Bias Voltage	10.1 Vdc ± 1.0 Vdc
Dynamic Output Impedance	<400 Ω typical
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Storage Temperature	-40°C to +100°C (-40°F to +212°F)
