Vibro-Meter IPC707 244-707-000-012 A1-B1-C9810-D3-E5-F2000-G2 factory- highly configured charge converter

Frequently asked questions
Q:What is the Vibro-Meter IPC707 244-707-000-012 A1-B1-C9810-D3-E5-F2000-G2?
A:The IPC707 244-707-000-012 A1-B1-C9810-D3-E5-F2000-G2 is a configurable signal conditioner (charge converter) designed to convert the charge output from Vibro-Meter piezoelectric sensors into a conditioned current signal for machinery protection and condition monitoring systems.

Q:What type of output does this IPC707 provide?
A:This configuration provides a current output (µA/pC·s) with an integrated transfer function, making it suitable for long-distance signal transmission to monitoring systems.

Q:Which industries commonly use the Vibro-Meter IPC707 244-707-000-012 A1-B1-C9810-D3-E5-F2000-G2?
A:The IPC707 is widely used in power generation, oil & gas, petrochemical, industrial process plants, and OEM rotating machinery applications where reliable vibration and dynamic pressure monitoring are required.

Description

The Vibro-Meter IPC707 244-707-000-012 A1-B1-C9810-D3-E5-F2000-G2 is a configurable IPC707 signal conditioner (charge converter) designed for use with Vibro-Meter CA series piezoelectric accelerometers and CP series dynamic pressure sensors. It converts the charge output from piezoelectric sensors into a conditioned signal for machinery protection and condition monitoring systems. This specific configuration includes A1 (standard environment), B1 (without diagnostics), C9810 (transfer sensitivity with integrator: 9,810), D3 (current output in µA/pC·s), E5 (5 Hz high-pass filter), F2000 (2,000 Hz low-pass filter), and G2 (DIN-rail adaptor included). The IPC707 offers configurable filtering and signal processing, supports a frequency range of 0.5 Hz to 20 kHz, and is suitable for vibration and dynamic pressure measurement in industrial rotating machinery applications. It is also designed as the successor to the IPC704, providing improved flexibility and compatibility with different piezoelectric sensor types.

Parameter

Model: IPC707 244-707-000-012  A1-B1-C9810-D3-E5-F2000-G2 factory- highly configured charge converter
Environment: Standard
Diagnostic: Without diagnostic
Transfer sensitivity: C9810-With integrator
Transfer unit: D3-current output in µA/pC·s
Operating Temp: -40°C to +85°C
High-pass Filter: 5 Hz
Low-pass Filter: D3-current output in µA/pC·s
Frequency Range: 0.5 Hz - 20,000 Hz (0.5 Hz to 20 kHz)

Application areas

The Vibro-Meter IPC707 244-707-000-012 A1-B1-C9810-D3-E5-F2000-G2 is designed for signal conditioning in piezoelectric sensor measurement chains. Typical application areas include:

• Heavy-Duty Gas & Steam Turbines: It processes raw charge signals from casing-mounted CA-series accelerometers. By integrating acceleration into velocity (mm/s), it helps plant operators monitor the overall vibration severity of turbine bearing housings.
• Centrifugal & Axial Compressors: Measures casing vibration near journal bearings to track machine health over long periods.
• Industrial Gearboxes: Monitors low-to-medium speed gear meshing frequencies and bearing wear that fall safely under the 2 kHz frequency limit.
