MCH MCH-K3010D-III Regulated Laboratory Grade DC Power Supply Capable

Frequently asked questions
Q:Can the MCH-K3010D-III be used for battery-related testing?
A:It can be used in low-power battery testing and charging-related applications where adjustable voltage and current control are required.

Q:How is the output status monitored during operation?
A:Voltage and current values are displayed through the built-in digital display, allowing users to check output conditions while adjusting the power supply.

Q:What protection functions are included with the MCH-K3010D-III?
A:The power supply includes current limiting protection to help prevent excessive output current during operation and protect connected devices.

Description

The MCH-K3010D-III is a compact and lightweight DC power supply module featuring a new structure and an attractive appearance. The MCH-K3010D-III supports full-load continuous output, with output voltage and current continuously adjustable within the standard range. It accepts 110V/220VAC input at 50/60 Hz and provides a 0–30V output voltage range with output current up to 10A.  It can be full load continuous output, the output voltage, current in the standard range continuously adjustable.In addition, the power supply to increase the temperature control output circuit, you can set the temperature to control the power output than the general DC power' supply is difficult to achieve very high stability, strong reliability and durability of the power supply, is the research department, Universities and enterprises, as well as personal care of the laptop repair and other high-stability DC power supply ideal choice.

Parameter

Model: MCH-K3010D-III Regulated Laboratory Grade DC Power Supply Capable
Input voltage: 110V/220VAC, 60Hz / 50Hz (state before order )
Output voltage rang: 0-30V
Output current rang: 0-10A
Voltage display: 0.01V
Current display accuracy: 0.01A
Effectiveness: ±0.5%
Source effect: ≤0.5%
Load effect: ≤0.3%
Operating environment: -10°C to + 60°C / 30%RHto 90%RH

Application areas

Based on its 30V/10A/300W specifications and dual CV/CC modes, the MCH-K3010D-III is highly versatile.Here are its primary application areas:

• Smartphone & Laptop Repair: Repair technicians often use adjustable DC power supplies when checking mobile devices and laptop boards. The 10A output of the MCH-K3010D-III can be applied for board-level troubleshooting, short-circuit checks, and micro-soldering related work.
• Drone & RC Maintenance: During RC and drone servicing, the power supply can be used to test motors, electronic speed controllers (ESCs), and control units by providing an adjustable DC source similar to a battery supply.
• Battery Balancing & Recovery: The CC (constant current) function gives users better control during battery-related work. It can be used for manual charging tests and recovery procedures involving lithium-ion, LiFePO4, and lead-acid batteries when proper charging conditions are .
