Bachmann TI214 Temperature Input Module

Description

The BACHMANN TI214 is a temperature input module designed for the Bachmann M200 automation platform, providing 14 independent temperature measurement channels within a single module. Each input channel can be individually configured to accept Pt100 or Pt1000 resistance temperature detectors (RTDs) using 2-wire or 3-wire connections, as well as Type J or Type K thermocouples, allowing multiple sensor types to be used simultaneously in one installation. This flexible channel configuration enables efficient adaptation to a wide range of industrial temperature monitoring applications. The module features 14-bit measurement resolution with 16-bit measured-value averaging, providing accurate and stable temperature acquisition while improving resistance to electrical interference. The averaging function can be configured from 16-fold to 64-fold, helping suppress noise in demanding industrial environments. Bachmann's 3-wire measurement technology compensates for voltage drops in symmetrical cable runs, delivering measurement accuracy comparable to more complex 4-wire systems while maintaining simpler field wiring. For reliable operation, the TI214 incorporates cable-break detection, external power supply monitoring, cold-junction temperature compensation, and 500 V galvanic isolation between the input channels and the control system. Each channel is electrically isolated from the system to improve measurement reliability and reduce the effects of electrical interference.

Parameter

Model: TI214 Temperature Input Module
Constant current Pt sensor: 2 mA (Pt100), 200 µA (Pt1000)
Digital resolution: 14 bits (16 bits representation with measured value averaging)
Galvanic isolation from system: 500 V
Voltage range: 18 to 34 VDC
Current consumption internal: Normally 160 mA at + 24VDC
Operating temperature: -30 to +60 °C
Rel. humidity operation: 5 to 95 % without condensation
Storage temperature: -40 to +85 °C

Frequently asked questions

Q:What is the BACHMANN TI214?
A:The BACHMANN TI214 is a temperature input module for the Bachmann M200/M1 automation system. It provides 14 temperature measurement channels within a single module and supports both RTD and thermocouple sensors.

Q:What diagnostic functions are available in the TI214?
A:The module includes cable-break detection, external power supply monitoring, and cold-junction temperature compensation for thermocouple measurements, helping improve measurement reliability.

Q:What is the advantage of the TI214's 3-wire RTD measurement technology?
A:The 3-wire measurement method compensates for voltage errors caused by cable resistance, providing measurement accuracy comparable to more complex 4-wire systems while maintaining simpler wiring.

Application areas

The Bachmann TI214 is a high-density, 14-channel temperature recording module designed for the ⁠Bachmann M1 automation system. Its heavy-duty noise suppression makes it optimal for EMI-heavy environments, the primary application areas for the Bachmann TI214 module include:

• Generator and Bearing Monitoring: Directly reads Pt100/Pt1000 sensors embedded in wind turbine generator windings and main bearings to prevent overheating.
• Cargo & Tank Thermal Tracking: Safely processes liquid or gas cargo temperature thresholds across long distance wiring lengths utilizing 3-wire noise-canceling technology
• Boiler and Steam System Automation: Handles high-pressure steam line thermal metrics inside process manufacturing facilities.
