Bachmann AIO216 16 Channel Universal Analog I/O Module

Frequently asked questions
Q:What is the BACHMANN AIO216?
A:The BACHMANN AIO216 is a universal analog input/output module for the Bachmann M200/M1 automation system. It provides 16 individually configurable analog channels that can be used for signal measurement or analog output within a single module.

Q:How many channels does the AIO216 provide?
A:The AIO216 features 16 analog channels, with each channel independently configurable according to the application requirements.

Q:What signal types are supported by the AIO216?
A:The module supports voltage inputs (±10 V to ±10 mV), current inputs (0–20 mA and 4–20 mA), Pt100/Pt1000 RTDs in 2-, 3-, and 4-wire configurations, J, K, T, N, E, R, S, and B thermocouples, as well as analog voltage outputs (±10 V) and current outputs (0/4–20 mA).

Description

The BACHMANN AIO216 is a universal analog input/output module designed for the Bachmann M200 automation platform, providing 16 configurable analog channels in a single compact module. Each channel can be individually configured to process voltage inputs, current inputs, temperature sensors, or analog outputs, allowing a single module to accommodate a wide variety of measurement and control tasks while reducing hardware requirements. The module supports voltage ranges from ±10 V to ±10 mV, current signals of 0(4) to 20 mA, Pt100/Pt1000 sensors in 2-, 3-, or 4-wire configurations, and standard J, K, T, N, E, R, S, and B thermocouples. Analog outputs are available as ±10 V voltage or 0(4) to 20 mA current signals. With 16-bit input resolution, 14-bit output resolution, and a configurable filter adjustable from 4 kHz to 0.5 Hz on each channel, the module delivers precise signal acquisition and stable analog control for demanding industrial applications. To enhance operational reliability, the AIO216 incorporates overload, short-circuit, and external voltage protection on all outputs, together with configurable measuring range monitoring up to ±105%, diagnostic messages for overload, overtemperature, and supply undervoltage, and 500 V galvanic isolation from the control system. An optional ColdClimate version is also available for environments where condensation resistance is required.

Parameter

Model: AIO216 16 Channel Universal Analog I/O Module
Voltage Input Ranges: ±10 V, ±5 V, ±1 V, ±500 mV, ±100 mV, ±10 mV
Current Input Ranges: 0 to 20 mA, 4 to 20 mA (supports standard 0(4)–20 mA loops)
RTD Temperature Sensors: Pt100, Pt1000 (Supports 2-, 3-, or 4-wire configuration methods)
Measuring Range Limit: Up to ±105% of the nominal range
Operating Temperature: -30°C to +60°C (Standard) / -40°C to +70°C (ColdClimate version)
Storage Temperature: -40°C to +85°C
Relative Humidity: 5% to 95% (Non-condensing for Standard; Condensation permissible for CC)

Application areas

The Bachmann AIO216 universal analog input/output module is heavily utilized in high-performance automation environments. Because every single one of its 16 channels can be configured for voltage, current, RTDs, thermocouples, or analog outputs, it is a primary choice for applications that demand high signal density, precise 16-bit resolution, and rugged survivability

• Grid Synchronization Panels: Measures voltage and current fluctuations to ensure safe energy injection into localized power grids.
• ColdClimate Marine Applications: The optional ColdClimate version handles harsh, condensing maritime environments on open deck machinery or Arctic shipping vessels.
• Industrial Kilns and Furnaces: Manages multi-zone heating profiles by acquiring precise micro-volt data from Type K/S/R thermocouples up to very high temperatures.
