VM600 MPC4 200-510-070-112 | VIBRO METER machinery protection card

in stock#

Brand/ Manufacturer:
VIBRO METER
Dimensions:
2x19x26.1cm
Weight:
0.4 kg
Country of Origin: :
Switzerland
Description:
VIBRO METER VM600 MPC4 200-510-070-112 machinery protection card

Inquiry now

Mfr. Part Number:	VM600 MPC4 200-510-070-112

Manufacturer:	VIBRO METER

Description:	VIBRO METER VM600 MPC4 200-510-070-112 machinery protection card

Full Description:	The VM600 MPC4 200-510-070-112 machinery protection card is the central element in the VM600 series machinery protection system (MPS)

Status:	In stock

Click to get price : : plcinfo@mooreplc.com : +86 18020776786 : mooreplc

Moore Automation Limited is not affiliated with or a distributor for VIBRO METER. The depiction, description, or sale of products featuring names, trademarks, brands, and logos is for identification and/or reference purposes only and does not indicate any affiliation with or authorization by any rights holder.

Product Description:
The VM600 MPC4 200-510-070-112 machinery protection card is the central element in the VM600 series machinery protection system (MPS), from Meggitt’s Vibro-Meter® product line. This very versatile card is capable of measuring and monitoring up to four dynamic signal inputs and up to two speed inputs simultaneously.

The VM600 MPC4 performs a self-test and diagnostic routine on power-up. In addition, the card’s built-in “OK system” continuously monitors the level of signals provided by a measurement chain (sensor and/or signal conditioner) and indicates any problem due to a broken transmission line, faulty sensor or signal conditioner.

Application:

Electric power industry: Vibration and axial displacement monitoring for gas turbines, steam turbines, hydro turbines and generators.
Oil and gas: Monitoring of key centrifugal compressors, reciprocating compressors and large pump sets on offshore platforms and oil refineries.
Heavy industry manufacturing: Blast furnace fans in steel mills, drive systems in paper mills, and large motors and reducers.
Petrochemical/processing industry: Online protection for process gas compressors, mixers and key auxiliary equipment.

Frequently Asked Questions (FAQ)

Q:How many inputs does the VM600 MPC4 support?
A:Each VM600 MPC4 card provides 4 dynamic inputs and 2 tacho inputs.

Q:What kind of inputs can the VM600 MPC4 handle?
A:It handles vibration, temperature, and other dynamic parameters from sensors such as accelerometers, velocity sensors, and proximity probes.

Q:Do you provide warranty as standard?
A:We provide a full 12-month warranty for the VM600 MPC4 200-510-070-112. So, if you have any problems within 12 months from the date of delivery, then you can contact our Team who will be happy to help and explain what your next steps should be.

If you need other brands products like below, please feel free write email to plcinfo@mooreplc.com

You will get Best price and Professional service (24/7)

Detailed Parameter	Part Number: VM600 MPC4 200-510-070-112
AC Range	±10 V max
Common Mode Voltage Range	−50 to +50 V
CMRR	>60 dB at 50 Hz
Crosstalk	−72 dB
Input Impedance	200 kΩ
Analog Frequency Range	DC to 60 kHz (−3 dB)
Current Measuring Resistor	324.5 Ω
Output Impedance	50 Ω
LP/HP Ratio in Pass Band	500 max
Alarm Scanning Interval	100 ms max
Operating Temperature	−25 to 65°C (−13 to 149°F)
Storage Temperature	−40 to 85°C (−40 to 185°F)
Operating Humidity	0 to 90% non-condensing
