IC695CHS007 General Electric high speed serial

Technical Specifications
Module Type: Universal Controller and I/O
Backplane Support:    PCI and High Speed Serial
Number of Slots: 7
Distance: N/A
Dimensions: 5.57 x 10.43 x 5.80 in. (H x W x D)
Internal Power Used:    240 mA @ 5 VDC, 600 mA @ 3.3 VDC

The GE Fanuc IC695CHS007 backplane is a universal backplane manufactured in the RX3i PACSystems product family. It is made as a replacement part for the GE Series 90-30 products, and it comes with an option for rack mounting as well as input voltage rating of 24 Volts. The users of the IC695CHS007 universal backplane are advised to mount it horizontally as well as to install it in a protective enclosure with at least a NEMA IP 20 Type 1 enclosure rating. This backplane also has the necessary grounding point and the terminal strip placed on the left side for the isolated input. Additionally, the backplane features an integrated grounding bar along with visible slot numbers that are used for its configuration and it also offers support for the systems and option modules from different manufacturers.

The IC695CHS007 backplane features 240 milliamps internal current draw at 5 volts DC, and 600 milliamps of internal current draw at 3.3 Volts DC and it has 7 slots for hosting modules Some of the supported components are the PCI input and output components such as the IC693 module. GE Fanuc backplanes including the IC695CHS007 universal backplane support safe usage in hazardous environments where enclosures that have a higher a level protection are required.  This backplane comes with a minimum protection rating of IP 54 for the hazardous locations. This universal backplane does not need a lot of space for installation, but it should have at least 4 inches of free space on all the sides for airflow for cooling. Additionally, the shipping dimensions of this backplane are 5.5 x 10.4 x 5.8 inches.
