Rated Operational Voltage: <= 690 V AC, 25...400 Hz
Control Circuit Voltage: 220 V DC
Rated Impulse Withstand Voltage: 6 kV
Conventional Free Air Thermal Current: 10 A (at 60 °C)
Associated Fuse Rating: 10 A gG
Mechanical Durability: 30 million cycles
Maximum Operating Rate: 180 cycles/min
Time Constant: 28 ms
Inrush Power: 5.4 W (at 20 °C)
Minimum Switching Voltage: 17 V
Minimum Switching Current: 5 mA
Insulation Resistance: > 10 MΩ
Ambient Air Temperature for Operation: -40…60 °C, 60…70 °C with derating
Ambient Air Temperature for Storage: -60…80 °C
Operating Altitude: 0...3000 m
