Schneider AD4000189-530 Cable Assembly

Parameter
Model: AD4000189-530 Cable Assembly
Component Type: Pre-fabricated Cable Assembly
Current Carrying Capacity: 1.5 A per conductor (Continuous)
Relative Humidity Limits: 5% to 95% RH (Non-condensing)
Dielectric Strength: 1000 VAC (Conductor-to-Conductor)
Conductor Gauge: 24 AWG
Rated Operating Voltage: 24 VDC / 60 VDC Max
Operating Temperature: -20 °C to 70 °C

Description

The Schneider AD4000189-530 is a cable assembly used for signal connection and system interconnection in Schneider industrial control equipment. It is installed between compatible modules or system components to provide the required electrical connection path for communication and signal transmission. The assembly is manufactured for use within Schneider automation hardware configurations, helping maintain proper wiring arrangement and connection between related devices. The AD4000189-530 cable assembly is commonly used as a replacement component in existing control system installations where the original cable configuration needs to be maintained.

Frequently asked questions

Q:What is the Schneider AD4000189-530 used for?
A:The AD4000189-530 is a termination panel cable assembly used for electrical connection between compatible Schneider industrial control system components.

Q:Where is the AD4000189-530 installed?
A:The cable assembly is installed within Schneider automation or control equipment configurations where the corresponding termination connection is required.

Q:Does the AD4000189-530 process or convert signals?

A:No. The cable assembly does not perform signal processing. Its function is to provide electrical connection and signal transmission between compatible system components.

Application areas

• Subsea Umbilical Termination Links: Serves as the internal cabinet bridge for routing signals coming from offshore subsea wellhead monitoring lines into the Triconex safety framework.
• High-Pressure Synthesis Loop Monitors: Acts as the exact drop-in replacement cable in aging fine-chemical or ammonia synthesis control cabinets, ensuring line-impedance standards are preserved during live hot-swapping or maintenance upgrades.
• Balance of Plant (BOP) Marshalling Enclosures: Chains multiple distributed I/O racks together inside high-density marshalling cabinets, keeping extensive wiring layouts organized.
