A9C30212 | Schneider Impulse Relay

Description

The A9C30212 is a impulse relay within the Acti9 iTL range featuring 2 normally open (2 NO) contacts and a rated operational current of 16 A. The device operates with a control supply voltage of 24 V DC or 48 V AC at 50/60 Hz and allows for the remote control of single-phase circuits via push-button impulses. It mounts on a 35 mm DIN rail and maintains an IP20 protection class according to IEC 60529. The unit includes a manual override switch on the front panel with a mechanical position indicator and provides an electrical durability of 200,000 cycles for AC-21 applications.

Parameter

rated current [In]: 16 A
control circuit voltage [Uc]: 24 V DC / 48 V AC 50/60 Hz
pole contact composition: 2 NO
rated operational voltage [Ue]: 250 V AC 50/60 Hz
impulse duration: 50 ms...1 s
switching frequency: 5 switching operations/minute or 100 operations/day
electrical durability: AC-21: 200,000 cycles / AC-22: 100,000 cycles
protection class IP: IP20 (IP40 in enclosure)

Frequently asked questions

Does the A9C30212 support manual operation?
Yes, it includes a manual override lever on the front panel for local control and visual status indication.

Does the A9C30212 require a continuous control signal?
No, as an impulse relay, it only requires an electrical pulse (50 ms to 1 s) to change and maintain its state.

Can auxiliary modules be added to the A9C30212?
Yes, it is compatible with iATL auxiliary modules for remote indication or centralized control.

Application areas:
Residential and Commercial Buildings: Multi-point lighting control in corridors and staircases using push-buttons.

Industrial Control Panels: Remote switching of auxiliary circuits and control of low-power inductive loads.

Energy Management Systems: Implementation of lighting logic in distribution boards to reduce standby energy consumption.

Public Infrastructure: Reliable circuit switching for lighting systems in transport hubs and public facilities.
