1 Year Warranty
:
:
:
Ambient Temperature Range: -20°C to +70°C (-4°F to +158°F)
Maximum Operating Pressure Port P: 350 Bar (5075 PSI); Port T depressurized
Pressure Range: 105 Bar (1523 PSI), 210 Bar (3045 PSI), 350 Bar (5075 PSI)
Fluid: Hydraulic oil as per DIN 51524 ... 51525
Fluid Temperature: -20°C to +70°C (-4°F to +158°F)
Nominal Flow: 3.8 LPM (1.0 GPM)
Minimum Pressure Setting: 7 Bar (102 PSI)
Series R1E02 direct operated, pressure relief valves are seated type valves typically used for remote pressure controls. In applications where the reliabilitiy and simplicity of a hydraulic remote control are preferred to an electrohydraulic system, Series R1E02 is an ideal solution.
