REC670/ ABB / IED

Brand/ Manufacturer:
ABB
Dimensions:
6.2cm*6.75cm *7.6cm
Weight:
0.124kg
Country of Origin: :
Sweden
Description:
IED

Inquiry now

Mfr. Part Number:	REC670

Manufacturer:	ABB

Description:	REC670 integrates advanced voltage control for transformers in a substation in a single IED

Full Description:	The IEDs feature a large HMI for local control and instant access to important data, such as settings

Sales manager: Tiffany Guan plcsale@mooreplc.com + 86 18030235313 dddemi33 2851195473

Hope we can do more business in future ! There will become your honest cooperation partners!

The REC 670 IED is used for the control, protection and monitoring of different types of bays in power networks. The IED is especially suitable for applications in distributed control systems with high demands on reliability. The IED can be used up to the highest voltage levels. It is suitable for the control of all apparatuses in any type of switchgear arrangements.
The control is performed from remote (SCADA/Station) through the communication bus or locally from a graphical HMI on the front of the IED showing the single line diagram. Different control configurations can be used, e.g. one control IED can be used per bay or one IED can be common for several bays. Interlocking modules are available for all common types of switchgear arrangements The control is based on the select-execute principle to give highest possible reliability. A synchrocheck function is available to interlock breaker closing.

A number of protection functions are available for flexibility in use for different station types and busbar arrangements. The auto-reclose for single-, two-, and/or three-phase reclose includes priority circuits for multi-breaker arrangements. It co-operates with the synchrocheck function with quick or delayed reclosing. Several breaker failure functions are included to provide a breaker failure function independent from the protection IEDs, also for a complete one- and a half breaker diameter.
