IS200TBAIH1C | General Electric | ANALOG INPUT

Processor Speed

10 MHz

I/O Points

512

Register Memory

4KBytes

Floating Point Math

No

16 BIT System

Yes

Processor

80188

CPU Type

Single slot CPU module

Total Baseplates per System

5 (1 CPU baseplate + 4 expansion and/or remote)

Load Required from Power Supply

350 milliamps from +5 VDC supply

Processor Speed

10 MegaHertz

Processor Type

80188

Operating Temperature

0 to 60 degrees C (32 to 140 degrees F) ambient

Typical Scan Rate

0.4 milliseconds per 1K of logic (boolean contacts)

User Program Memory (maximum)

16K Bytes

Discrete Input Points - %I

512

Discrete Output Points - %Q

512

Discrete Global Memory - %G

1280 bits

Internal Coils - %M

1024 bits

Output (Temporary) Coils - %T

256 bits

System Status References - %S

128 bits (%S, %SA, %SB, %SC - 32 bits each)

Register Memory - %R

2048 words

Analog Inputs - %AI

128 words

Analog Outputs - %AQ

64 words

System Registers (for reference table viewing only; cannot be referenced in user logic program)

16 words (%SR)

Timers/Counters

680

Shift Registers

yes

Built-in Ports

1 (uses connector on PLC power supply). Supports SNP/SNP-X slave protocols. Requires CMM module for SNP/SNP-X master, CCM, or RTU slave support; PCM module for RTU master support.

Communications

LAN - Supports multidrop. Also supports Ethernet, FIP, Profibus, GBC, GCM, GCM+ option modules.

Override

yes

Battery Backed Clock

yes

Interrupts

no

Type of Memory Storage

RAM and optional EPROM or EEPROM

PCM/CCM Compatibility

Yes
