IS200STCIH4A | General Electric terminal board

Brand/ Manufacturer:
General Electric
Dimensions:
3.6cm*13cm*13.5cm
Weight:
0.3kg
Country of Origin: :
United States
Description:
PLC Module

Inquiry now

Mfr. Part Number:	IS200STCIH4A

Manufacturer:	General Electric

Description:	Part Number: IS200STCIH4A ED Product Type: MK VIe Terminal Board Series: GE Speedtronic Mark VIe In stock ready to ship

Full Description:	The IS200STCIH4A developed by General Electric is a PCB component created as part of the Mark VI series. The Mark VI is one of the last gas and steam turbine management systems.It was designed as a small board built with a terminal board located along one long edge that has fifty-one screw connections.

Sales manager: Tiffany Guan plcsale@mooreplc.com + 86 18030235313 dddemi33 2851195473

Part Number: IS200STCIH4A ED
Product Type: MK VIe Terminal Board
Series: GE Speedtronic Mark VIe

The IS200STCIH4A developed by General Electric is a PCB component created as part of the Mark VI series. The Mark VI is one of the last gas and steam turbine management systems.

It was designed as a small board built with a terminal board located along one long edge that has fifty-one screw connections. The terminal ring located on either side of the terminal board is labeled E1 and E2. The board features a single 37-pin (female) D-type connector located opposite the terminal strip as well as a single three-position female plug. There are also two round openings cut into the board that are located opposite each other on the short edges of the board. Additionally, the board is populated by over 80 resistors, capacitors, diodes and a single integrated circuit.

General Function

1. The armor can be used in harsh conditions and has a wide range of input/output (I/O) arrangements.
2. Read the position of limit switches, analog process variables, and complex positioning systems.
3. Operate electric motor, pneumatic or hydraulic cylinder, magnetic relay, solenoid, or analog output
4. Industrial, sequential relay control, motion control.
5. Process control, distributed control system, and network

Widely Application
1. Power industry, the elevator industry, parking lot, automobile, automobile supporting.
2. Feed industry, aluminum smelting machinery, refrigeration industry.
3. Iron and steel industry, combustion control system, non-ferrous metal smelting.
4. Glass industry, construction machinery, textile machinery, water treatment. More types of modules we are applying for you.
