IS200EGEDMH1AFG | GE Detector Module

Description

General Electric IS200EGEDMH1AFG Detector Module is a high-reliability industrial control module designed for the GE EX2100 excitation control system and Mark VIe turbine platforms. It is primarily used to monitor generator field circuits for ground leakage and insulation faults, helping protect excitation systems, synchronous generators, and associated power equipment from electrical damage and unexpected shutdowns. The module continuously detects AC/DC ground faults by injecting a controlled test signal into the field winding and measuring leakage current, ensuring safe and stable operation in power generation and heavy industrial applications.

Parameter

Series: EX2100 Excitation Control System
Power Rails: +5 V
Isolation: 500 V channel-to-channel
Measurement Range: 0 – 500 kΩ leakage
Current Limitation: Approximately 80 mA
Internal Supply Conversion: ±65 VDC, ±15 VDC, +5 VDC Isolated

Frequently asked questions

What is the isolation rating of the General Electric IS200EGEDMH1AFG Detector Module?
The General Electric IS200EGEDMH1AFG Detector Module provides 500 V channel-to-channel isolation.

Can the General Electric IS200EGEDMH1AFG Detector Module monitor DC ground leakage?
Yes, the General Electric IS200EGEDMH1AFG Detector Module can monitor DC ground leakage conditions in excitation field circuits.

Does the General Electric IS200EGEDMH1AFG Detector Module support isolated power conversion?
Yes, the General Electric IS200EGEDMH1AFG Detector Module includes isolated internal supply conversions for multiple voltage outputs.

Application areas:
Petrochemical & Chemical: Supports continuous-process plants by protecting synchronous motors and excitation equipment used in large-scale chemical production systems.

Oil & Gas: Applied in offshore platforms, refineries, LNG facilities, compressor stations, and pipeline operations where reliable turbine-driven generators and motor systems are essential.

Power Generation: Used in gas turbines and generator control systems for drive control, LAN communications and real-time monitoring in thermal and combined-cycle power plants.

Metallurgy & Steel: Supports large rolling mill motors and industrial generators.
