IC695ETM001| General Electric

GE Fanuc manufactures the IC695ETM001 Ethernet interface module as part of the RX3i PACSystems series. This unit is designed and intended to enable controllers in the RX3i PACSystems series to interface with the VersaMax, Series 90-30, and other controllers over the Ethernet Networks.

 It features an Ethernet Interface that can operate at 10/100 Mbps and that can sense the speed and the type of cable connected. A pair of twisted cable measuring up to 100 meters in length is used to connect network nodes at 10 Mbps. Additionally, a Category 5 twisted-pair cable with a length of 100 meters is used to connect the network nodes at 100 Mbps.

The IC695ETM001 Ethernet interface features an Ethernet port that supports the use of full-duplex and half-duplex nodes. Additionally, both straight-through and crossover Ethernet cables can be used for the network connections.

This Ethernet interface module supports 1 MAC address along with 1 IP address. It comes with an embedded Ethernet switch that enables the daisy chaining of the Ethernet nodes.

High Performance

Fast Servo Loop Update (1 ms for IC693APU301, 2 ms for IC693APU302).
Block Processing time under 5
elocity Feed forward and Position Error Integrator to enhance tracking
High resolution of programming units. Position: -8,388,608...+8,388,607 User Units Velocity: 1 ... 8,388,607 User Units / sec Acceleration: 1 .. 134,217,727 User Units / sec / sec

Easy to Use
Simple and powerful Motion Program instruction
Simple 1- or 2-axis motion programs with synchronized block
Program support for a short motion program which can be created in Logicmaster 90 configuration
Non-volatile storage for 10 programs and 40
Motion Programmer Status Screen for servo
