General Electric VMIVME-7697-850 Board Computer

•  VMIVME-7697-850
•  850 MHz Pentium III Processor
•  128 MB RAM
•  No Flash Memory
•  Pentium II processor with speeds up to 333 MHz
•  Up to 512 Mbyte SDRAM using two 144-pin SODIMM modules
•  64-bit AGP SVGA controller with 4 Mbyte SGRAM
•  On-board Fast Ethernet controller supporting 10BaseT and 100BaseTX interfaces
•  On-board UltraDMA-33 hard drive and floppy drive controllers with CompactPCI J3 I/O

MICROPROCESSOR — The VMIVME-7697 brings Intel® Pentium III processor with MMXTM to VMEbus. The Pentium III processor has 32-bit addressing and a 64-bit data bus. Its superscalar architecture allows three instructions to be executed per clock cycle.

A dynamic branch prediction unit, separate instruction and data caches, MMX technology, and streaming SIMD extensions with 70 new instructions also increase the Pentium III processor’s performance. The Pentium III processor has 256 Kbyte of advanced transfer cache (ATC). ATC is an L2 cache integrated on the same die as the processor core. ATC is available on the 550 MHz and higher processors.

DRAM MEMORY — The VMIVME-7697 accepts a 144-pin SODIMM SDRAM module for a maximum memory capacity of 512 Mbyte. The on-board DRAM is dual ported to the VMEbus.
