PLC Module 1783-LMS8 Ethernet Switch

Frequently asked questions
Q:Does the 1783-LMS8 use Cisco technology?
A:Yes. The Stratix 8000 Series incorporates Cisco® switching technology together with Rockwell Automation features, giving both automation engineers and IT teams a familiar way to configure and monitor industrial networks.

Q:Why do many users select the 1783-LMS8?
A:One of its key benefits is the combination of managed switching capabilities and straightforward integration with EtherNet/IP control systems. The eight Ethernet ports, together with Cisco® networking technology, make it well suited for day-to-day operation, diagnostics, and network maintenance in industrial environments.

Q:Where can the 1783-LMS8 be used?
A:You can install the 1783-LMS8 in most industrial Ethernet networks. It is frequently applied to connect controllers, HMIs, variable frequency drives, and distributed I/O in manufacturing, material handling, water treatment, food processing, and similar automation systems.

Description

The PLC Module 1783-LMS8 is an Ethernet communication hardware component categorized as a lightly managed Ethernet switch. The 1783-LMS8 is primarily used to implement industrial Ethernet I/P networks for Distributed I/O architecture, enabling data exchange between Human Machine Interface (HMI), Supervisory Control and Data Acquisition (SCADA), and facilitating communication between other automation devices for messaging functions. This 1783-LMS8 switch is designed to provide reliable network connectivity in industrial environments where moderate management capabilities are required without the complexity of fully managed switches.The switch is designed for DIN rail installation in industrial control panels and is suitable for demanding manufacturing environments where secure, managed Ethernet communication and reliable network operation are required.

Parameter

Model: 1783-LMS8 Ethernet Switch
Transmission speed: 10/100 mbps
Network Media: 1 Male RJ45 to Male RJ45 Patchcord
Power supply voltage: 12-24 VDC
Input current: 0.4 to 0.2 A (SELV)
Operating Temperature: -40 °C to +60 °C (-40 °F to +140 °F)
Relative Humidity: 5% to 95%, non-condensing

Application areas

The PLC Module 1783-LMS8 Stratix 8000™ managed switch is specifically engineered for high-availability industrial automation networks (EtherNet/IP). The primary application areas include:

• Automotive Manufacturing: In automotive plants, robotic cells, paint booths, conveyor sections, and PLC cabinets are usually connected through the same industrial Ethernet network. The 1783-LMS8 can be installed as part of this network to manage communication between production equipment.
• Food and Beverage Industry: Packaging, filling, and processing equipment installed throughout food production facilities typically communicate over an industrial Ethernet system. The 1783-LMS8 is one option for handling communication between these production assets, including areas that undergo regular cleaning.
• Water and Wastewater Treatment: A treatment plant normally operates a large number of pumps, instruments, and dosing systems located across different process areas. The 1783-LMS8 is often integrated into the industrial Ethernet network to exchange data between field equipment and the control room.
• Oil, Gas, and Mining: Operations such as conveying, material handling, well sites, and process plants often require dependable industrial networking. The 1783-LMS8 can be incorporated into these systems to connect field equipment with the control network under demanding operating conditions.
