P0926CP ZCP270 Foxboro I/A series control processor

Brand/ Manufacturer:
FOXBORO
Dimensions:
3.5cm*45cm*22.7cm
Weight:
1.04kg
Country of Origin: :
United States
Description:
I/A Series Control Processor

Inquiry now

Mfr. Part Number:	P0926CP ZCP270

Manufacturer:	Foxboro

Description:	P0926CP \| Foxboro ( by Schneider Electric ) \| ZCP270 Control Processor IN STOCK READY TO SHIP

Full Description:	The fault-tolerant version of the ZCP270 consists of two single-width processor modules. These modules install in adjacent ZCP270 slots in a 1x8 or 2x8 mounting structure and connect to a fault-tolerant connector to allow for high-speed communication between the modules.

plcsale@mooreplc.com + 86 18030235313 dddemi33 2851195473

Foxboro P0926CP ZCP270 Specification

Manufacturer: Foxboro
Product No.: P0926CP
Model: ZCP270 Control Processor
Type: Microprocessor-based AMD Elan SC520 (running at 100 MHz) with stored programs, using highspeed communication capability
Memory (per processor): 16 MB SDRAM, 32 MB flash memory
Operating temperature: 0 to 60°C (32 to 140°F)
Operating Relative humidity: 5 to 95% (Noncondensing)
Operating Altitude: -300 to +3,000 m (-1,000 to +10,000 ft)
Operating Vibration: 0.5 g (5 to 500 Hz)
Single-width processor module. The fault-tolerant version consists of two single-width processor modules, with an interconnecting fault-tolerant connector.
Dimensions (HxWxD), approx: 22.8cm x 3.43cm x 44.7cm

Foxboro P0926CP ZCP270 OVERVIEW
The Z-Module Control Processor 270 (ZCP270) is an optionally fault-tolerant, Z-form factor controller. The ZCP270 performs regulatory, logic, timing, and sequential control together with connected Fieldbus Communications Modules (FCMs) and Fieldbus Modules. It also performs data acquisition and alarm detection and notification.

The ZCP270 connects to The MESH control network and FCM100Ets/FCM100Es via standard fiber optic 100 Mbps Ethernet. The FCM100Et interfaces the 2 Mbps Module Fieldbus used by the 200 Series FBMs and the FCM100E interfaces the 2 Mbps Module Fieldbus used by the 200 Series FBMs or the 268 Kbps Fieldbus used by 100 Series FBMs. Depending on sizing considerations, the ZCP270 can be used with a mix of FCM100E and FCM100Et modules.
